Carbon steel square and rectangular pipes are carefully crafted from high-quality carbon steel, with unique designs for square and rectangular cross-sections that endow excellent structural load-bearing capacity. Widely used in core fields such as construction, machinery, and automobiles, it creates stable structures for various projects, adapts to diverse needs with precise size specifications, and has good processing performance to facilitate efficient construction and manufacturing. It is a key force driving the development of many industries, injecting reliable quality and infinite possibilities into modern engineering and industry.
| Standard | ASTM/ GB/ JIS/ EN Standard |
| Diameter | 20x10mm-400x600mm |
| Thickness | 0.8-12mm |
| Length | 1-12m, according to customers'requirements, stock is 6m |
Parameter of Carbon Square And Rectangular Tubes
| Outer Diameter | 20*10-400*600mm | ||||||
| Wall thickness | 0.8-12mm | ||||||
| Length | 1-12m ,according to customers'requirements, stock is 6m | ||||||
| Material | Q195, Q215 ,Q235 ,Q345, Q195-Q235 | ||||||
| Standard | ASTM A500,GBT 6728,GB T 3094 | ||||||
| Packing | 1)Big OD: in bulk 2)Small OD: packed by steel strips into bundles 3)According to the requirement of the customers. | ||||||
| Zinc Coating | Pre-: 60-150g/m2 Hot Dip Galvanzied:>200g/m2 | ||||||
| Certificate | ISO 9001-2000 | ||||||
| Technique | Welded / ERW / Cold drawn | ||||||
Hollow Section--GBT 6728/ASTM A500
| Size(mm) | Thickness(mm) | Size(mm) | Thickness(mm) | |||
| 10*10 | 0.6-1.0 | 20*10 | 0.6-1.0 | |||
| 12*12 | 0.6-1.0 | 25*12 | 0.6-1.0 | |||
| 16*16 | 0.6-1.2 | 38*19 | 0.6-1.5 | |||
| 19*19 | 0.6-1.5 | 50*25 | 0.6-1.5 | |||
| 20*20 | 0.6-1.5 | 50*30 | 1.0-3.0 | |||
| 25*25 | 1.0-2.75 | 60*40 | 1.5-3.5 | |||
| 30*30 | 1.0-2.75 | 75*50 | 1.5-4.0 | |||
| 32*32 | 1.0-3.0 | 80*40 | 1.5-4.0 | |||
| 38*38 | 1.0-3.0 | 100*50 | 2.0-6.0 | |||
| 40*40 | 1.0-3.5 | 100*60 | 2.0-6.0 | |||
| 50*50 | 1.0-5.0 | 100*75 | 2.0-6.0 | |||
| 60*60 | 1.0-6.0 | 120*60 | 3.0-6.0 | |||
| 63.5*63.5 | 1.0-6.0 | 120*80 | 3.0-6.0 | |||
| 70*70 | 1.5-6.0 | 125*50 | 3.0-6.0 | |||
| 75*75 | 1.5-6.0 | 125*75 | 3.0-6.0 | |||
| 80*80 | 2.0-6.0 | 150*50 | 3.0-6.0 | |||
| 90*90 | 2.0-6.0 | 150*75 | 3.0-6.0 | |||
| 100*100 | 2.3-6.0 | 150*100 | 4.0-12 | |||
| 120*120 | 4.0-6.0 | 160*80 | 4.0-6.0 | |||
| 125*125 | 4.0-6.0 | 175*100 | 4.0-12 | |||
| 150*150 | 4.0-8.0 | 200*100 | 4.0-12 | |||
| 200*200 | 6.0-12 | 200*150 | 4.0-12 | |||
| 250*250 | 6.0-12 | 250*150 | 5.0-12 | |||
| 300*300 | 6.0-12 | 300*200 | 5.0-12 | |||
| 400*400 | 6.0-12 | 400*200 | 5.0-12 | |||
Features of Carbon Square And Rectangular Tubes
High strength and good load-bearing capacity. Carbon steel itself has relatively high strength. After being made into square or rectangular pipes, their structures can effectively distribute and transfer external forces, are not prone to deformation or damage, and provide reliable support for building and mechanical structures.
Diverse specifications and size adaptability. There are a rich variety of specifications to choose from. The dimensions such as side lengths and wall thicknesses can be flexibly adjusted and customized according to different engineering designs and usage requirements.
Good processing performance.
Compared with some special alloy material pipes, the raw material cost of carbon steel square and rectangular pipes is relatively low, and their production process is relatively mature with high production efficiency, effectively controlling the overall cost.
Carbon steel materials have good recyclability. After the pipes reach the end of their service life or are removed during engineering renovations, carbon steel square and rectangular pipes can be easily recycled. After being remelted and processed, they can be made into new steel products again, which conforms to the concept of sustainable development.
